Female-Female Standoffs

Technical Description:

1) Click to download Spacer FF (Hex Spacer) -SS 303 datasheet.

2) Click to download Spacer FF (Hex Spacer) -U-SS 303  datasheet.

3) Click to download Spacer FF (Hex Spacer) -SS 316 datasheet.

4) Click to download Spacer FF (Hex Spacer) -U-SS 316 datasheet.

5) Click to download Spacer FF (Hex Spacer) -AL.docx datasheet.

6) Click to download Spacer FF (Hex Spacer) -BR-Ni datasheet.

7) Click to download Spacer FF (Hex Spacer) -NY-MI-BLACK.docx datasheet.

8) Click to download Spacer FF (Hex Spacer) -NY-NY.docx datasheet.



Category:

Description

Female-Female Standoffs are essential components in the world of electronics and mechanical assembly. Also known simply as “standoffs,” these cylindrical spacers are designed with internal threads on both ends, allowing them to accept threaded fasteners such as machine screws or bolts. Their primary purpose is to maintain a fixed distance between two components, typically circuit boards or panels, while providing a secure mounting structure. These standoffs are widely used in printed circuit board (PCB) assemblies, control panels, robotics, communication systems, and various enclosures in industrial and commercial electronics.

Hex spacers with internal threads, also known as female-female hex standoffs, are mechanical components designed to maintain a specified distance between two parts in an assembly. Their hexagonal shape allows for easy installation and removal using standard wrenches, providing a secure and stable connection.

Design and Structure of Female-Female Standoffs

A typical female-female standoff is a hexagonal or round spacer with a threaded hole (usually a machine screw thread like M3, M4, #4-40, #6-32, etc.) on both ends. This configuration allows the standoff to be inserted between two components using male screws or studs. The hexagonal shape is common because it provides easy grip for tightening with a wrench or pliers during installation.

These standoffs come in a wide range of lengths, usually starting from as short as 3 mm up to 50 mm or more, depending on the required spacing between the components. The thread depth is also designed to ensure a strong mechanical bond and prevent loosening under vibration or stress.

Materials and Sizes:

These spacers are available in various materials to suit different application needs:

  • Aluminum: Offers a lightweight solution with good strength, suitable for applications where weight reduction is essential.
  • Brass: Provides excellent corrosion resistance and electrical conductivity, making it ideal for electronic applications.
  • Stainless Steel: Known for its high strength and resistance to corrosion, suitable for demanding environments.
  • Nylon: Offers electrical insulation and is resistant to corrosion, making it suitable for lightweight and insulated applications.

Common thread sizes include M3, M4, and #4-40, catering to various assembly requirements.

Applications of Female-Female Standoffs

1. Printed Circuit Boards (PCBs)
One of the most common uses of female-female standoffs is in the mounting of PCBs within enclosures. They allow safe spacing between the board and its housing or between multiple stacked boards, preventing short circuits and providing mechanical support.

2. Control Panels and Displays
In control systems, standoffs are used to space interface panels or displays from the housing or internal components.

3. Robotics and Automation Equipment
Standoffs are used to mount sensors, controllers, and other electronic components within robotic systems, ensuring proper alignment and spacing.

4. Industrial and Telecom Equipment
Standoffs help in organizing and spacing electronic modules, power supplies, or network hardware in racks or enclosures.

5. 3D Printers and Embedded Systems
They are frequently used to mount microcontrollers, Raspberry Pi, Arduino, and other boards securely within custom-designed frames or enclosures.
